Captures, stores, analyzes, and transmits by simplifying workflow with user-friendly usability.
Features:
- Simplifying workflow with "AUTO" operation
- 30 min. full disclosure and Live acquisition comparison
- Easy ECG file data conversion
- Enhanced sampling rate for data accuracy - With 8,000Hz per second sampling rate, it is designed to improve clinical decision for cardiology with accurate ECG interpretation algorithm and full storage of 200 ECG data per 30 minutes
- Advanced algorithm and Analysis - With long term recordings of 3, 5, 10 min, it features various analysis algorithms of ECG diagnosis.
- Patient Data Management in Mind
- Touch screen, Rotary push-knob
- Display: 800 x 480 pixel resolution, 7" Color TFT wide display 12 channels preview, ID, HR, Gain, Speed, Power status
- Dimensions: 300(W) x 290(H) x 89.5(D) mm, Approx. 3.5 kg
- ECG leads: Simultaneous 12 Leads Resting ECG
- Battery type: Replaceable ans Rechargeable, Lithium ion, 10.8V, 3250mA
- Communication: LAN, WIFI(option), USB flash driver, USB barcode scanner
- Safety conformity: Class I, Type CF defibrillation-proof applied part
BMS plus offers care givers the workflow flexibility for
- Data Preview
- Device remote control
- File conversion to PDF, XML, JPG, BMP, MFER, DICOM for data transfer through PACS
- Direct print-out, magnifying and comparing ECG trace, measuring ECG complex, adding comments
Environmental Operation:
- Ambient Temperature: 10 to 40°C
- Relative Humidity: 30 to 85%
- Atmospheric Pressure: 70 to 106KPa
Line power:
- Input: 100 - 240Vac, 1.5-0.75A, 50-60Hz,
- Output: 15Vdc, 4.2A
Standard Accessory: Patient cable(1 EA), Limbs electrodes(1 SET), Chest electrodes(1 SET), ECG chart paper(1 EA), Power cord(1 EA), Operation manual and ECG diagnosisguide(1 EA)
