Wide range of applications: dermatological, cosmetic, dental and oral surgery, plastic surgery, aesthetic surgery, veterinary surgery
The single board microcontroller and digital display guarantee high safety and reliability under all conditions.
Thanks to their ergonomic design and excellent safety features, they offer outstanding professional surgical results.
Technical specifications:
- Max output power CUT: 50 W - 400 Ohm
- Max output power CUT/COAG1: 45 W - 400 Ohm
- Max output power CUT COAG2: 40 W - 400 Ohm
- Max output power COAG: 40 W - 400 Ohm
- Operating frequency : 600 KHz
- Operating circuit : F
- Selectable input voltage : 115 - 230 Vac
- Mains frequency : 50 - 60 Hz
- Electrical input power : 200 VA
- Dimensions W x D x H mm: 190 x 85 x 239
- Weight: 2.5 kg
- Controls: Patient/Leave circuit monitoring, Output power monitoring, Self-monitoring
- Safety: EN60601-1, EN60601-1-2, EN60601-2-2
- Electrical class: I CF
- MDD 93/42/EC Class: II b
- Resistance: 400 Ohm
Standard accessories:
- Disposable handle
- Waterproof foot switch (30577)
- MB flat neutral plate with cable (30564)
- Set of 6 short autoclavable electrodes, Ø 2,4 mm, length 5 cm (30501/2/4/7/9/10)
- Power cable 2 m - Schuko plug
