With advanced breath tracking technology - A.V.T. (Advanced Valve Technology) (when used with a mouthpiece). Efficient use of medication, minimal medication loss!
The Advanced Valve Technology is an improved version of the V.V.T. technology, designed to ensure maximum treatment efficiency.
Dual valve technology that allows the patient to inhale the maximum amount of medicine. Optimises drug flow during inhalation and reduces drug loss during exhalation. By synchronising aerosol flow and respiration, the therapeutic effect of the inhaled medicine is optimised.
(Note: synchronisation of breathing is only possible with the use of a mouthpiece.)
When inhaled, the drug solution flows into the airways, when exhaled, the built-in valve closes thanks to the breath-tracking technology, so that the drug solution does not flow unnecessarily into the airspace. This makes medication use more efficient.
Most of the medicine is broken down into even smaller particles, allowing for more optimal inhalation.
Inhalation:
The drug pumped into the drug channel mixes with the compressed air (aerosol) generated by the compressor, passing through the distribution barrier, ready for inhalation.
During inhalation, the valve on the inhalation roof (inhalation valve) opens, allowing air to enter the inhaler. The air mixes with the aerosol, which the patient inhales through the mouthpiece. At this stage the exhalation valve remains closed, preventing the aerosol from being wasted.
Exhalation:
When exhaling through the mouthpiece, the valve on the inhalation roof closes, preventing the aerosol from escaping. The aerosol remains in the inhaler and becomes available for the next inhalation cycle. The exhaled air exits the mouthpiece through the exhalation valve.
Highly efficient mode of operation:
efficient (maximum) use of medication
minimum drug loss
longer treatment time
Quick set-up and operation mode
Fast delivery of the medication solution via the convenient mask
Newly designed soft-edge mask provides a more comfortable treatment experience
Auxiliary connector (for treatment in the supine position)
For the treatment of lower respiratory tract diseases (asthma, chronic obstructive pulmonary disease (COPD), bronchitis, bronchiolitis, cough, colds).
Product features:
Good quality, excellent appearance
High quality, high quality, high quality products
Easy to use at home
Easy to clean and disinfect
3 years warranty
Electrical characteristics: 230 V, ~ 50 Hz. Power consumption: 140 VA
Noise level: approx. 55 dB
Full service and accessories purchase
Medication tank capacity: 10 ml
Particle size (MMAD*): approx. 2,65 µm
Aerosol output (2ml, 1% NaF): approx. 0.7 ml
Aerosol release rate (2 ml, 1% NaF): 0,12 ml/min
Operating temperature/humidity: +5°C to +40°C and 15% to 85% relative humidity, 700-1060 hPa
Storage temperature/humidity/atmospheric pressure: -20°C - +60°C, 5% - 95% relative humidity, 500-1060 hPa
Weight: 1.3 kg (compressor only), Size: 180 (diameter) x 104 (height) mm
Package contents: inhaler, inhaler set, air tube, mouthpiece, additional connector (for treatment in lying position), adult mask, child mask, additional connector for child mask, carrying case, 5 spare air filters, instructions for use
*MMAD=Mass Median Aerodynamic Diameter
