The Contec CMS50L is a simple to use and easy to carry pulse oximeter device that can be placed on the wrist for comfortable wear and easy measurements. The device has a built-in sensor that non-invasively measures oxygen levels and heart rate.
In addition, the Contec CMS50I can be connected to a computer or other device so that the data can be easily exported and evaluated using analysis software.
It can be used before or after exercise, but is not recommended during exercise.
Features:
- Small, light and convenient
- Low power consumption
- Operation menu for the function setting
- SpO2 value display,Pulse rate value display, bar graph display,Pulse waveform display
- With PI display
- The display mode can be changed
- Screen brightness can be changed
- A pulse rate sound indication
- Multi-time segment storage
- Alarm function (adjustable)
- Battery capacity indication
- Low-voltage indication
- The storage data and real-time data can be uploaded to computers
- Connected with an external oximeter probe
Main performance:
- Display Mode: 1.5' Color OLED display
- Screen Resolution: 128*128
- SpO2 Measuring Range: 0%-100%, (the resolution is 1%).
- Accuracy: 70%-100%: ±2%, Below 70% unspecified.
- PR Measuring Range: 30bpm-250bpm, (the resolution is 1bpm)
Measurement Performance in Weak Filling Condition:
- SpO2 and pulse rate can be shown correctly when pulse-filling ratio is 0.4%, SpO2 error is ±4%, pulse rate error is ±2 bpm or ±2%
- Resistance to surrounding light: The deviation between the value measured in the condition of man-made light or indoor natural light and that of darkroom is less than ±1%.
- Power Consumption: less than 100mA
- Voltage: DC 3.6V-4.2V
- Power Supply: Voltage 3.7 rechargeable lithium battery
- Battery working hour: 10 hours
- Battery working life: Charge and discharge no less than 500 times.
- Safety Type: Interior Battery, BF Type
Accessories
- A user manual
- A data line
- A disk (PC software)
- An adult-oximeter probe
- Two One-off adhesive SpO2 probe
- A power adapter (GTM41076-0605;CMS0105)
Physical Identity:
- Dimension: 63(L) x 55(W) x 15(H) mm
- Weight: About 45g (with one lithium battery)
Qualification: Passed CE FDA
